HVAC Energy Optimisation: Cutting the Cost of Your Biggest Building Load

Heating, ventilation, and air conditioning accounts for 40–60% of energy consumption in most commercial buildings. It’s also the area where the gap between what a system costs to run and what it should cost is typically widest — because HVAC is almost always set and forgotten, operating on schedules and setpoints that made sense when the building was commissioned and haven’t been revisited since.

---

Three levers, different economics

HVAC optimisation has three distinct cost tiers: controls and scheduling (minimal capex, highest ROI), maintenance (recurring cost that prevents efficiency degradation), and equipment replacement (high capex, justified only when plant approaches end of life).

Starting with controls is almost always the right sequence. Optimising setpoints, occupancy scheduling, and outside air compensation before committing to equipment spend can deliver 10–15% consumption reduction on existing plant. Equipment replacement on top of an already-optimised system delivers incremental gains. Equipment replacement on a system still running default commissioning schedules from fifteen years ago often disappoints.

---

Controls optimisation in practice

The most common HVAC energy waste patterns in UK commercial buildings: heating and cooling running simultaneously in the same zone (the dead band problem, where heating and cooling setpoints overlap); plant starting on fixed time schedules regardless of occupancy or external temperature; and fresh air dampers set to fixed positions regardless of whether free cooling is available outside.

A building management system that responds to occupancy sensors, external temperature, and internal CO₂ levels — rather than fixed schedules — typically cuts HVAC energy use by 15–20% with no change to comfort conditions. On a building spending £60,000 per year on energy with HVAC at 50% of that load, that’s £4,500–6,000 per year from controls optimisation alone.

---

Maintenance and efficiency degradation

Dirty filters increase fan energy consumption by 15–20% by restricting airflow. Blocked condenser coils reduce chiller efficiency. Low refrigerant charge causes compressors to run longer to achieve the same cooling effect. None of these failures are dramatic enough to trigger a call-out — they simply consume progressively more energy while delivering the same visible output.

A structured maintenance programme — filter replacement on schedule, annual coil cleaning, refrigerant charge checks — is the lowest-cost form of HVAC energy management. Its absence is the most common cause of gradual efficiency drift on sites where consumption has been creeping up year on year without obvious explanation.

---

Variable speed drives on fans and pumps

VSDs are subject to the cubic law: reducing fan speed by 20% cuts fan energy consumption by approximately 49%. For air handling units running at constant speed to meet peak demand conditions regardless of actual load — common in older installations — retrofitting VSDs is one of the most cost-effective capital interventions available.

A 15kW fan motor running 3,500 hours per year at £0.22/kWh costs approximately £11,550 per year at full speed. At 80% speed, the same fan costs around £5,900 — saving roughly £5,650 per year. A VSD retrofit for a 15kW motor costs £800–1,500 installed, giving payback of typically 2–4 months per unit, with further savings from reduced mechanical wear on bearings and belts.

---

HVAC and demand management

HVAC start-up — particularly morning warm-up when multiple units switch on simultaneously — creates demand peaks that affect Triad readings and DUoS red band charges on pass-through contracts. Sequencing unit start times to stagger the demand spike reduces peak kW demand without affecting comfort, and can have a material impact on network charges for larger sites.

Free cooling economisation is also often overlooked: when outside air temperature is sufficiently low, fresh air can provide cooling without running the refrigeration cycle at all. Modern HVAC controllers can automate this switchover, but many sites running older controls — or controls never properly commissioned — have this capability disabled or bypassed.

---

The procurement connection

HVAC load shape affects the consumption profile your supplier prices against. A site that has optimised HVAC to flatten its morning demand peak and reduce overnight baseload presents a lower-risk, lower-cost profile at tender. We review half-hourly consumption data as standard before going to market — the demand profile is part of the commercial conversation with suppliers, not just an operational footnote.

📱 WhatsApp: 07360 272168 | 📧 hello@telnergy.com | 📞 01202 028888 Telnergy Limited · Independent commercial energy consultancy since 2002 · Ofgem registered TPI · ADR Ref E3561 · CRN 04576876 · Christchurch, Dorset

---

FAQ

How do I know if my HVAC system is over-consuming?

The clearest signal is half-hourly consumption data showing a large morning demand spike as the building warms up, or significant overnight baseload when the building is unoccupied. If your HVAC is responsible for 50%+ of your energy use, a basic BMS review — checking actual setpoints and schedules against what’s programmed — is a sensible first step before any capital spend.

What’s the dead band and how do I fix it?

The dead band is the temperature range between the heating setpoint and the cooling setpoint. If heating is set to activate below 21°C and cooling below 22°C, the two systems fight each other in a 1°C overlap. Widening the dead band — heating below 19°C, cooling above 24°C, for example — eliminates simultaneous heating and cooling and typically saves 5–10% of HVAC energy with a BMS setpoint change that takes minutes.

Should I replace old HVAC equipment or optimise what I have?

Optimise first, replace later. Controls optimisation and maintenance typically deliver 10–20% savings at low cost. New equipment on a poorly controlled system will underperform its efficiency rating. The correct sequence: fix the controls, establish a maintenance regime, then assess whether equipment replacement is justified on the residual consumption. In most cases, replacement adds value only when plant is genuinely near end of life or when a change of use has made existing equipment fundamentally oversized.
